Color Doppler Ultrasound Scanner AM-K8 4D
Internal patient file information management system can record patient number, name, check number, check date and so on, and can be searched and managed by numbering, checking number, name and so on.
Description
Summary of main specifications
- Trolley type all digital color Doppler ultrasonic mainframe
- Ultrasonic host operating system: Windows 7 operating system.
- Spectrum pulse Doppler.
- Direction energy Doppler.
- Real time three synchronization.
- Space composite imaging: the requirement is 3 level, visual adjustable.
- Organized harmonic imaging technology.
- 4B imaging mode.
- One key intelligent optimization.
- Support multilingual user interface.
- Monitor: 17 inches, high definition LED
- Physical clipboard: display the saved image below the screen, which can be deleted directly.
- The system has the function of on-the-spot upgrade
- Presupposition: for different inspection of the viscera, preset the inspection conditions for the best image, reduce the adjustment of the operation, and the commonly used external adjustment and combination regulation.
- Language: Chinese/English/Russian/Spanish/French/Arabic/Vietnamese/Portuguese
/Indonesian
- The probe interface is 3
Technical Specifications
| PARAMETER | SPECIFICATION |
| Probes | |
| Convex probe | 2.0MHz/3.0MHz/3.5MHz/4.0MHz/5.5MHz |
| Linear probe | 6.0MHz/6.5MHz/7.5MHz/10.0MHz/12.0MHz |
| Trans-vaginal probe | 5.0MHz/6.0MHz/6.5MHz/7.5MHz/9.0MHz |
| R11 Micro convex probe | 5.5MHz/6.0MHz/6.5MHz/7.5MHz/9.0MHz |
| R15 Micro convex probe | 5.5MHz/6.0MHz/6.5MHz/7.5MHz/9.0MHz |
| 4D Volume probe | 2.0MHz/3.0MHz/3.5MHz/4.0MHz/5.5MHz |
| Under each probe, there is a selection of specialist and viscera mode and rapid entry detection. | |
| Two-dimensional imaging mode | |
| Gain | 0-100, step 2 visible adjustable |
| TGC | 8 segment adjustable |
| Image optimization | visible and adjustable over 6 levels |
| Dynamic range | 0-270dB 15 level visual adjustable |
| False color | 7, visible and adjustable |
| Smooth treatment | 8, visible and adjustable |
| Edge enhancement | 8, visible and adjustable |
| Sound power | 0-15 stage, step 7%, visible adjustable |
| Display depth | ≥320mm |
| Maximum focus number | 4 focal points, which can be moved throughout the whole process. |
| Scan line density 256 visible tunable | |
| Gray scale | 1-16 level visible visible and adjustable |
| Filtering | 3 kinds |
| Scanning range | 50%-100% |
| Frame correlation | 0-4 level, visible and adjustable |
| The screen has real-time display of voice power, probe frequency, dynamic range, pseudo color, gray scale and other 14 parameters can be adjusted | |
| Color imaging mode | |
| Color frequency | ≥5 frequency conversion, visible adjustable |
| Color deflection | equipped with |
| C afterglow | 8, visible and adjustable |
| Color map | 7, visible and adjustable |
| Color reversal | adjustable |
| B/C split screen synchronous display function | equipped with |
| Color baseline | 7, visible and adjustable |
| Color line density | adjustable |
| Spectrum Doppler mode | |
| Sampling volume angle correction | -80 degree to 80 degree adjustable |
| Sample volume | 0.5mm-48mm visually adjustable |
| Frequency | ≥ 5, visible and adjustable |
| Baseline | 7 adjustable |
| Smooth | 8 files can be adjusted |
| False color | 7 kinds of adjustable |
| Maximum display blood flow measurement speed 25m/s, minimum resolvable blood
flow measurement speed |
0.1mm/s |
| Measurement and analysis function | General measurement distance, area, angle, time, slope, heart rate, velocity, acceleration, neck hyaline layer, spectrum tracing, resistance index / pulsatility index, etc. |
| Professional software package: abdomen, volume, ratio, obstetrics and Gynecology, small organs, carotid artery, Urology, heart. | |
| Graphic and text management system | |
| Host built in ≥ 120G solid state hard disk to start fast and stable | |
| Movie playback | 600 frames |
| Internal patient file information management system | can record patient number, name, check number, check date and so on, and can be searched and managed by numbering, checking number, name and so on. |
| The type of report is 3. Provide picture proof. | |
| One key fast report graphic and text management | |
| Interface | |
| USB interface | 2 |
| VGA interface | 1 |
| RJ-45 interface | 1 |
| VIDEO interface | 1 |
| Grounding wire interface | 1 |
| Technology, after-sales service and other requirements | |
| After acceptance, the warranty is free for two years | |
| Manufacturer has ISO13485 certification. |
